Description
Features
- Wavelength Range 1650nm
- Fiber Output Power 15mW
Applications
- Wavelength Range 1650nm
- Fiber Output Power 15mW
Parameters
Optical and electrical characteristics
|
Parameter |
Symbol |
Condition |
Min. |
Typ. |
Max. |
Units |
|
Forward voltage |
VF |
IF=30mA |
1.2 |
1.6 |
V |
|
|
Threshold current |
I(TH) |
CW |
15 |
20 |
mA |
|
|
Fiber output power |
PO |
CW,IF=130mA |
15 |
mW |
||
|
Peak wavelength |
ëp |
CW, PO =15mW |
1625 |
1655 |
nm |
|
|
Spectral linewidth* |
Äë |
CW, PO =15mW |
2 |
MHz |
||
|
Side mode suppression ratio |
SMS |
CW, PO =15mW |
35 |
dB |
||
|
Monitoring Current(PD) |
IR(E) |
CW, PO =15mW |
0.1 |
mA |
||
|
Dark current(PD) |
Ir(0) |
CW,VDR=5V |
100 |
nA |
||
|
Tracking error |
ER |
IR(E)=constant |
-0.5 |
+0.5 |
dB |
|
|
Cooling capacity* |
ÄTPE |
PO=15mW,Tcase=70deg |
45 |
deg. |
||
|
Peltier current |
IPE |
Tcase=-5 to 70deg. |
Ordering Information
| Isolator | Output Power | Saddle | Connector |
| 0:NO | 1:0.3-0.5mW | 1:A | 00:NO |
| 1:Single | 2:0.5-1.5mW | 2:B | FC:FC |
| 2:Double | 3:1.5-2.0mW | 3:C | ST: ST |
| 4:2.0-4.0mW | 4:D | SC:SC | |
| 5:E |
