Description
Regular Price: $1.83 (USD)
Volume Price :$1.28 - $1.74
Add multiple items to the quote list and get a quote from us .
Weight | 20 g | ||
---|---|---|---|
Optical connector | SC/UPC |
Transfer Mode | Singlemode |
Return Loss | ≥65dB |
Attenuation Accuracy | 1-5dB ±0.5, 6-10dB ±0.7, >10dB ±1.0 |
Operating Wavelength | 1260~1620nm |
Optical Input Power | 200mW |
Operating Temp Range | -40~75°C |
Humidity | 95%RH |
Optical connector | SC/UPC |
---|---|
Transfer Mode | Singlemode |
Return Loss | ≥65dB |
Attenuation Accuracy | 1-5dB ±0.5, 6-10dB ±0.7, >10dB ±1.0 |
Operating Wavelength | 1260~1620nm |
Optical Input Power | 200mW |
Operating Temp Range | -40~75°C |
Humidity | 95%RH |
Characteristics | Unit |
Conditions |
Values |
---|---|---|---|
Attenuation | dB |
UPC APC |
1 ~ 30 1 ~ 20 |
Return Loss | dB |
UPC APC |
≥50 ≥60 |
Operating Wavelength | nm |
- |
1310 and 1550, 1240 - 1600 |
Attenuation Accuracy | - |
1 ~ 4dB 5 ~ 30dB |
≤0.5dB ≤10% |
Operating Temperature | °C |
- |
-40 ~ +75 |
Storage Temperature | °C |
- |
-40 ~ +85 |
Polarization Dependent Loss | dB |
- |
≤0.2 |
Relative Humidity | % |
75°C |
95 |
Vibration | dB |
10 ~ 55, 2Hrs |
∆IL≤0.2 |
Impact | dB |
1.5m, 5 drops |
∆IL≤0.2 |
