Description
| Features | Applications |  |
|
|
Specifications
| Parameters | Values | ||||
| Center Wavelength(nm) | 1510 ~ 1590 | ||||
| FBG Profile | Apodized | ||||
| Wavelength Tolerance(nm) | +/-0.5 | ||||
| FBG Length(mm) | 3 | 5 | 10 | 15 | |
| Reflectivity | ≥70% | ≥75% | ≥90% | ≥90% | |
| Bandwidth (at –3dB)(nm) | ≤0.7 | ≤0.7 | ≤0.3 | ≤0.3 | |
| SLSR(dB) | ≥10 | ≥15 | |||
| Recoating | Acrylate, Polyimide or Metal | ||||
| Proof Test(Kpsi) | ≥100 | ||||
| Fiber Type | SMF-28e Or Polyimide Fiber(OFS BF04446) | ||||
| Fiber Termination | Bare Fiber, FC/UPC, Or FC/APC | ||||
| Pigtail Length | 1 meter (Typical) | ||||
| Operating temperature(℃) | SMF-28 fiber: -40 ~ 120; Polyimide Fiber: -40 ~ 300 | ||||
Metal Recoating
| Parameters | Unit | Values |
| Maximum metalized length | mm | 40 |
| Thickness of metal recoating | μm | 3-4 |
