FBG Array

Availability: In Stock

Volume Price :$70 - $95

Add multiple items to the quote list and get a quote from us .

Request a Quote
Add the items to the quotation list, we will quote you price according to the total quantity , and you can continue to pay the order online if you accept our quotation.
Tag:

Description

Features
Applications
  • No splicing point
  • Customer defined grating characteristics and spacing
  • High Stability and Reliability
  • Long fiber distance
    		•
  • Distributed Sensing Measurement
  • Wavelength Reference
  • Aerospace Engineering
  • Load monitoring for power transmission
    		•

    Specifications

    Parameters Values
    Center Wavelength(nm) 1510 ~ 1590
    Wavelength Tolerance(nm) +/-0.5
    FBG Length(mm) 3 5 10 15
    Reflectivity ≥70% ≥75% ≥90% ≥90%
    Bandwidth( at –3dB)(nm) ≤0.7 ≤0.7 ≤0.3 ≤0.3
    SLSR(dB) ≥15
    Mini. Spacing(mm) 10
    Spacing Accuracy(mm) ≤1
    Recoat Acrylate Or Polyimide
    Proof Test(Kpsi) ≥100
    Fiber Type SMF-28e Or Polyimide Fiber(OFS BF04446)
    Fiber Termination Bare Fiber, FC/UPC, FC/APC Or E2000
    Pigtail Length Customized
    Operating temperature(℃) -40 ~120
